ERA PRODUCT


P1 DDX Prime Motion

Regular price $125,000.00

LAUNCH SPECIAL
The first 20 DDX Prime Units sold will be offered at the special price of $125,000.00. After the first 20 units are gone, the pricing will return to the DDX Prime MSRP of $175,000.00
SYSTEM BUILD AT A GLANCE
• Driven DynamiX Prime Motion System • G-Active Seating Belt Tensioner • AeroSurge Wind Simulator  • Tillet Carbon Fiber Seat • Asetek Invicta 27nm Wheel Base • Asetek Invicta P1 Editon Wheel • Cube Controls Pro V2 w Suede Round Wheel and Asetek Quick Release • 3 x Simucube Active Pedals • P1 Edition BDH H1SQ Hybrid Shifter  • Heusinkveld E-Brake • Free Standing Custom Monitor Stand for Triple 77" OLED Screens  • Gaming PC with RTX 5090 series (VR Ready) • 5.1 Surround Sound System • Corsair Wireless Gaming Headset • Headset Hook • Keyboard / Mouse • PC Rack Mount System • Surge Protectors • Full cable management and additional accessories.

PC Overview:

Custom Built, Liquid Cooled PC with 14th Gen Intel i9 and RTX 5090 GFX Card. 64 Gigs of RAM, 2 Tb NVME hard drive, Programable LED lighting system. Software loaded and preconfigured, peripherals are updated, configured, and buttons mapped. iRacing, ACC, AMS2 installed as default. All settings configured and tested. Additional software can be installed if requested.
With Flight Add-On Microsoft Flight is installed and configured. DCS can be installed as well if desired.

System Comes Built, Software Loaded, Pre-Configured and tested by our Team.
Full iRacing Suite Included plus 1 yr subscription and $200 in credits.
• Chassis and Monitor Stand are separate from each other for ease of placement.
• Monitors are not installed on the stand as they need protected within boxes.

• Ships in a 60" x 60" x 60" Wooden Crate. Truck will have Liftgate and pallet jack.

Flight Controls can easily be added to the rig.

WHITE GLOVE HOME INSTALL INCLUDED IN PRICE

MOTION SYSTEM SPECIFICATIONS

Motion System Specifications

Motion system maximums:

Sway (X): 740mm (+/- 370mm), 560 mm/s, 100 m/s^2 (10G)

Heave (Y): 200mm (+/- 100mm), 145 mm/s, 25 m/s^2 (2.5G)

Surge (Z): 650mm (+/- 325mm), 610 mm/s, 110 m/s^2 (11G)

Yaw (A): 62 deg (+/- 31 deg), 150 deg/s, 28000 deg/s^2

Pitch (B): 57 deg (+/- 28.5 deg), 40 deg/s, 7000 deg/s^2

Roll (C): 52 deg (+/- 26 deg), 40 deg/s, 7000 deg/s^2

*Single-DoF maximums - travel range is reduced for combined multi-DoF motion.

Velocity is approximate and varies over travel range.

Acceleration is approximate peak, short-duration values (vibrations, impacts) at most aggressive settings.

Motion system responsiveness:

Latency: 3ms

Bandwidth (frequency response): 0 - 500Hz

Command rate: 1000Hz

G-Active Seating:

Max sustained braking force: 800N (180 lbf, ~2.5G)

Max sustained cornering force: 400N (90 lbf)

AeroSurge Wind Simulator:

100% output: 24 mph, 78 dBA

50% output: 12 mph, 64 dBA

Acceleration: 0 - 100% output in 400ms

*as measured at typical driver seating distance

Power consumption:

Motion system: 120V 15A, 100 - 400W typical

Total system power (with PC, monitors, etc.): 120V 15A, 900 - 1400W typical

Dimensions:

Operating footprint (floor footprint and motion envelope): 9.4’ x 8.0’ (2.9m x 2.4m)

Weight (approximate): 1100lb (500kg)

Floor dynamic load (approximate): 1900lb (860kg)

Minimum doorway width for transport / install: 29.5”
